water filter High Performance , Weatherproof Twin Filter + UV Whole House Water Sanitation System , For Raw Water, Rainwater, Tank & Bore (ncwhwptuv)
$2,540.00
Quick Overview (ncwhwptuv)
- Treats Raw, Rain, Tank & Bore* Water for Households of 3+ People
- Durable Tamper-Resistant & Weather-Proof 304 Brushed Stainless-Steel Enclosure to Protect Your System
- Corrosion Resistant Electropolished 304 Stainless Steel Ultraviolet Sanitation Chamber
- Ultra-Strong Tempered Glass Panel to Easily View & Safeguard Electrical Components and Pressure Gauges
- Customisable Twin Pre-Filter Options: Choose from Our Range of Sediment and Carbon Filters Compliant to National Sanitation Foundation/ANSI Standard No. 42 in 20″ x 4.5″ Size
- Fine Filtration + Fast Acting Sanitisation Kills 99.9% of Parasites, Bacteria & Viruses at High Volume Flow Rates
- Watermark Certified to Australian Plumbing Standards AS/NZS 3497
- Quick and Straightforward Installation
- What’s In The Box?
-
- Durable & Sleek Tamper-Resistant & Weather-Resistant 304 Brushed Stainless-Steel Enclosure to Protect Your System
- 1 x H7-90-Lamp – 48W High Output UV Lamp, 4 Pin 436mm length (12 month replacement)
- 1 x H7-90-Thimble – Quartz Thimble 470mm length
- 2 x GT7-2NSF-OR – O-Rings 23mm outer diameter
- 1x H7-90-PS – Certified Ballast 42-105W with a standard 3 pin Australian Plug + Earthing Cable
- 2 x premium Filter Housings 20″ x 4.5″
- 2 x Pressure Gauges
- 1 x 20inch x 4.5inch Premium 5 micron poly spun sediment filter.
- 1 x 20inch x 4.5 inch premium 5 micron Coconut carbon block
-
Replacement Parts for the HPF-UV System:
- NCH7-90-Lamp – 48W High Output UV Lamp, 4 Pin 436mm length
- NCH7-90-Thimble – Quartz Thimble 470mm length, 23mm outer diameter
- (NCGT7-2NSF-OR) – 2x O-Rings 23mm outer diameter
- NC7-90-BPS – Certified Ballast 42-105W Australian Plug + Earthing Cable
- replacement service kit https://northcoastwatertanks.com.au/product/whole-house-weather-proof-water-filter-system-service-kit-for-ncwhwptuv/
-
High-Performance Weatherproof Twin Filter + UV Whole House Water Sanitation System (ncwhwptuv)
Overview
The North Coast Water High-Performance Twin Filter + UV System is designed for effective water treatment from various sources, including raw water, rainwater, tank, and bore water. Here’s what makes it stand out:
Key Features
-
Efficient Pre-Treatment Design
-
Utilizes two 20″ × 4.5″ Big Blue housings for high flow rates and longer cartridge life.
-
Typical setup includes:
-
Stage 1: Sediment filter (5–20 micron)
-
Stage 2: Carbon block filter (0.5–5 micron)
This arrangement enhances water clarity, taste, and odor while protecting the UV system.
-
-
-
Robust UV Disinfection Capacity
-
Delivers:
-
40 mJ/cm² at 75 L/min
-
30 mJ/cm² at 105 L/min
A UV dose of 40 mJ/cm² effectively inactivates bacteria, viruses, and protozoa.
-
-
-
Weatherproof Outdoor Installation
-
Features a 304 stainless steel enclosure with a tempered glass viewing panel and protected electronics, suitable for harsh Australian conditions.
-
-
WaterMark Certification
-
Compliant with AS/NZS 3497 standards, ensuring it meets plumbing requirements for licensed installations in Australia.
-
What UV Can and Cannot Do
UV Effectively Targets:
-
Bacteria
-
Viruses (e.g., E. coli, Salmonella)
-
Protozoa (e.g., Legionella)
UV Does Not Remove:
-
Salts, heavy metals, iron, manganese, nitrates, PFAS, hardness minerals, and dissolved chemicals. Testing bore water is recommended to determine additional treatment needs.
Maintenance Costs
Regular maintenance is essential:
-
Sediment Filter: Every 3–12 months
-
Carbon Filter: Every 6–12 months
-
UV Lamp: Annually (even if still glowing)
-
Quartz Sleeve: Every 1–2 years
-
O-rings: As needed
- service kit at Northcoastwatertanks.com.au
Flow Rate Considerations
With a flow rate of 75–105 L/min, this system is suitable for:
-
Typical shower: 8–12 L/min
-
Household peak demand: 20–40 L/min
-
Large rural homes: 40–60 L/min
Overall Assessment
Ideal for rainwater tanks, rural properties, and whole-house drinking water treatment, this well-specified system combines large filter housings, a proper UV chamber, and a weatherproof enclosure. However, ensure a recent water analysis for bore water sources to confirm sufficiency.
Why Choose North Coast Water Tanks for Your Home Filtration Water Needs?
Over Three Decades of Expertise in Water Filtration
For more than 30 years, North Coast Water Filtration has been a leader in Australia’s home water filtration industry. From the early days of basic systems to today’s advanced filtration technologies, our extensive experience guarantees you receive the best advice and products. Celebrate with us as we continue to provide trust, quality, and sustainability in every drop!
Competitive Pricing You Can Count On
At North Coast Water Filtration, we take pride in offering affordable prices that often beat our competitors. As a family-run business, we prioritize quality and customer satisfaction, ensuring you receive the perfect solution for your home water filtration needs. Remember, not all filtration systems are created equal!
Versatile Filtration Options to Suit Your Home
Our water filtration systems are available in various configurations to meet a wide range of household needs. Whether you require a compact under-sink system or a larger whole-house filtration solution, we have options tailored to every requirement. Enjoy clean, safe water in your home with our versatile filtration solutions.
Certified Quality for Your Peace of Mind
We ensure that our water filtration systems meet the highest quality standards. Our manufacturing processes and material suppliers comply with strict regulations, providing a transparent and traceable quality assurance process.
Odour-Free and Taste-Free Water
The high-quality materials used in our filtration systems are designed to remove impurities, ensuring your water is both odour-free and taste-free. If you seek a reliable water filtration system from a trusted company known for excellent service, look no further than North Coast Water Tanks
Ensure Your Filtration System Meets All Standards!
Our products are certified for safety and performance, ensuring they meet Australian standards for drinking water. We only offer systems that have passed rigorous testing, providing you with the confidence of safe, clean water for your family. For expert advice and personalized service, call us today at 0407 002 833.
Reliable Delivery Across Australia
North Coast Water Tanks proudly delivers our home water filtration systems throughout Northern NSW, Mid North Coast, Northern Rivers, Coffs Harbour, Ballina, Lismore, Tweed Heads, Byron Bay, and South East Queensland. Quality water filtration is just a phone call away!
