Product Code: DJ72
WATERPRONCDJ72
Specifications:
• Max Flow: 71L/min
• Max Head: 40m
• 5 – 8 Taps
• Inlet/Outlet: 25mm (1”)
• Stainless Steel Casing
• 2-Year Warranty
• Run Dry Protection
• Automatic Controller
• Approved for Drinking Water – AS4020
• Includes 1″ Y Strainer
These value-packed jet pumps are suitable for the supply of water to the house and garden. Quiet running reliable jet pump is suitable for suction lift for underground tanks or tanks at differing levels.
Domestic water supply and irrigation
Water storage tank pump set
Water transfer
Pressure boosting
Garden irrigation
Sheds, small workshops
SUITABLE FOR
Average lowset house or two storey unit, toilets & laundry (DJ58: 1 bathroom, DJ72: 3 bathrooms MAX)
Noryl jet, diffuser and impeller
Grade 304 stainless steel casing & shaft
Carbon/ceramic mechanical seals for reliability
Quick plug pressure controller
Thermal overload protection
Ingress Protection IP44
Insulation Class B
| AMPS | 4.7 | P1 | P2 | 0.93 | 0.75 |
|---|---|---|---|
| RATED FLOW | 40 L/min | RATED HEAD | 25m |
| MAX FLOW | 71 L/min | MAX HEAD | 40m |
| SUCTION LIFT | 8 | NO. OF TAPS | 5 – 8 |
| CABLE LENGTH | 1.5m | INLET | OUTLET | 25mm |
| SIZE (L x W x H) mm | 410 x 190 x 350 | ||
